51.2V 200Ah Rack-Mounted LiFePO4 Battery
The 51.2V 200Ah rack mount LiFePO4 battery delivers 10.24kWh of reliable energy for residential solar storage, commercial energy systems, off-grid applications and backup power. Its modular design makes installation, maintenance and future capacity expansion easier.
Key Features
- 51.2V nominal voltage and 200Ah rated capacity
- 10.24kWh nominal energy
- More than 6,000 charge and discharge cycles
- Integrated intelligent battery management system
- Modular rack-mounted design
- Flexible parallel expansion for increased storage capacity
- Stable LiFePO4 chemistry with excellent thermal stability
- Suitable for use with compatible hybrid and off-grid inverters
- Communication and monitoring options available
- OEM branding and customized battery solutions supported
Applications
This rack-mounted LiFePO4 battery is suitable for:
- Residential solar energy storage
- Small commercial energy storage systems
- Off-grid solar power systems
- Backup power systems
- Telecom and communication equipment
- UPS and emergency power applications
- Modular battery cabinets and rack systems
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | SMP-MU002 |
| Battery Chemistry | LiFePO4 |
| Nominal Voltage | 51.2V |
| Rated Capacity | 200Ah |
| Nominal Energy | 10.24kWh |
| Cycle Life | More than 6,000 cycles |
| Installation Type | Rack-mounted |
| Dimensions | 770 × 565 × 165mm |
| Weight | Approximately 78kg |
| Battery Management | Intelligent BMS |
| Communication | Configurable according to system requirements |
| Scalability | Supports modular system expansion |
Actual cycle life may vary depending on depth of discharge, temperature, charging conditions and operating environment.
Intelligent Battery Management
The integrated BMS monitors the battery’s operating status and provides protection against overcharge, over-discharge, overcurrent, short circuit and abnormal temperature conditions.
Communication protocols and inverter compatibility should be confirmed according to the selected inverter and project requirements before ordering.
Flexible and Scalable Configuration
Multiple battery modules can be configured to meet different energy requirements. Battery capacity, communication protocol, rack quantity, cabinet design and monitoring functions can be customized according to the application.
Available customization services include:
- OEM logo and packaging
- Customized voltage and capacity
- CAN or RS485 communication configuration
- Inverter communication matching
- Battery rack or cabinet configuration
- Wi-Fi or Bluetooth monitoring options
Wholesale and OEM Battery Supply
Solarayen supplies rack-mounted LiFePO4 batteries for distributors, importers, solar installers, EPC companies and energy storage system integrators.
Contact us with your required voltage, capacity, inverter model and order quantity to receive a suitable battery configuration and quotation.
FAQ:
How much energy does this 51.2V 200Ah battery provide?
The battery provides 10.24kWh of nominal energy. The actual usable energy depends on the configured depth of discharge, inverter settings, operating temperature and battery management system.
Can multiple rack-mounted batteries be connected in parallel?
Yes. Multiple battery modules can be connected to expand the total storage capacity. The maximum number of parallel batteries depends on the BMS configuration, communication protocol and inverter compatibility. Please provide your required system capacity before ordering.
Which inverters are compatible with this battery?
The battery can work with compatible hybrid and off-grid inverters. CAN or RS485 communication can be configured according to the inverter model and project requirements. Please send us the inverter brand and model so that we can confirm communication compatibility.
Is OEM customization available?
Yes. We support OEM logos, customized packaging, battery rack configurations, communication protocols and monitoring options for distributors, importers, installers and energy storage system integrators.
What information is required for a quotation?
Please provide the required quantity, destination country, inverter model, application and total storage capacity. We will recommend a suitable battery configuration and prepare a detailed quotation.
